Product Details:
Payment & Shipping Terms:
|
Brightness: | 300 Nits | Lcd Size: | 18.5 |
---|---|---|---|
Brand Name: | AUO | Application: | Visual Doorbell, Digital Camera, Tablet Pc, DVD Player |
Backlight: | LED | Color Pixel Arrangement: | RGB Vertical Stripe |
Interface: | LVDS | Product Name: | LCD Panel, LCD Screen |
High Light: | tft lcd display module,lcd panel screen |
AUO 18.5" tft industrial lcd display 1280x1024 G185XW01 V0
Quick Detail:
1.Lcd size:18.5"
2. Physical Size(mm): 358.5(H) x 296.5(V) Typ. x 15.8(D) Max.
3.Resolution: 1280 × 3(RGB) × 1024
4.Brightness: 300nits
5. Weight: 1650g (typ.)
6. Interface: LVDS
7. Backlight: LED
Applications:
industrial control and car application lcd panel.besides,we have different size lcd panel apply to different fileds. such as tablet pc ,health care, Digital video cameras, digital cameras, portable DVD player, visual doorbell,.
Specifications:
Items | specifications |
Screen Diagonal(inch) | 18.5" |
Active Area(mm) | 409.8(H)*230.4(V) |
resolution | 1280 × 3(RGB) × 1024 |
Pixel Pitch(mm) | 0.30*0.30 |
Pixel Arrangement | R.G.B. Vertical Stripe |
brightness | 300nits |
Display Mode | Normally White |
contrast ratio | 1000 : 1 (Typ) |
surface treatment | Anti-glare, Hardness 3H |
Viewing Angle (H/V) | 170/160 |
Weight(gram) | 1650 |
Physical Size(mm) | 358.5(H) x 296.5(V) Typ. x 15.8(D) Max. |
Electrical Interface | 1 channel LVDS |
backlight | LED |
Support Color | 16.7M color |
RoHS Compliance | RoHS Compliance |
Competitive Advantage:
+ we are the agent of AUO/CPT/Innolux in ShenZhen China
+ Secure Ordering
+ Delivery Date Guarantee
+ 100% Low Price Guaranteed
HK SEBO Electronics Co., Ltd. was founded in 2007. Our main products are all kinds of lcd panels. As the agent of AUO/CPT/Innolux,in Shenzhen, China, we have supplied our lcd panels to many lcd monitor, lcd TV, notebook pc, digital photo frame, DVD player, industrial display and car display factories from at home and abroad
With the advantage of our lcd panels, we have been engaged in the R&D of led backlight for lcd panel since the year of 2010 to satisfy customer;s different demand of lcd panel's brightness.
