Product Details:
Payment & Shipping Terms:
|
| Highlight: | driver simulators,driving simulator training |
||
|---|---|---|---|
|
No. |
DOF |
Strock limit |
Speed |
Acceleration |
||
|
Axial |
Direction |
Single Dof |
Max |
|||
|
1 |
X axis translation |
Before and after |
±0.18m |
± 0.20 m |
±0.7 m/s |
±7 m/s² = 0.71 g |
|
2 |
Y axis translation |
Left and right |
±0.15m |
± 0.17 m |
±0.7 m/s |
±7 m/s² = 0.71 g |
|
3 |
Z axis translation |
Vertical |
±0.14 m |
±0.16 m |
±0.5 m/s |
±10 m/s² = 1.02 g |
|
4 |
X-axis |
Roll |
±14° |
±14° |
±34°/s |
＞225°/s² |
|
5 |
Y-axis |
Pitch |
16°／－14° |
22°／－18° |
±35°/s |
＞225°/s² |
|
6 |
Z-axis |
Course |
±15° |
±18° |
±35°/s |
＞ 225°/s² |
|
Item |
Data |
|
(GML) |
1500 kg |
|
Payload (reduce the weight on the hinge bracket) |
1000 kg |
|
X-axis maximum moment of inertia |
1,500 kg m² |
|
Y-axis maximum moment of inertia |
1,500 kg m² |
|
Z-axis maximum moment of inertia |
1,500 kg m² |
|
The maximum height from the geometric center of the platform to the load center |
1.0 m |
